Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission
  • Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission
  • Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission
  • Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission
  • Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission
  • Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission
  • Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission
  • Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission
Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission

Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission

Tempat asal Cina
Nama merek CENO
Sertifikasi CE,RoHS,UL,ISO9001
Nomor model ECN000-02P5-03U2-01EG-01F
Rincian produk
Perlindungan (Kelas IP):
IP51
Kelembaban kerja:
60% RH
Suhu Kerja:
-20 ℃ ~+60 ℃
Tegangan Peringkat:
0~48VAC/VDC
Sirkuit & Arus:
2 sirkuit * 30A(48V); 3 grup * USB2.0; 1 grup * Ethernet 1000M
Kekuatan dielektrik:
≥300VAC@50Hz
Resistensi Isolasi:
50MΩ@300VDC
Kebisingan listrik:
Maks 30mΩ (50rpm)
Panjang kawat timbal:
Rotor: 450mm; Stator: 200mm
Kecepatan Kerja:
0 ~ 300rpm
Cara rotasi:
Sisi Stator: Pemasangan flensa
bahan kontak:
Logam mulia/Emas menjadi Emas
Bahan perumahan:
Paduan Aluminium
Syarat Pembayaran & Pengiriman
Kuantitas min Order
1 buah
Harga
Dapat dinegosiasikan
Kemasan rincian
Karton
Waktu pengiriman
Dari rak
Syarat-syarat pembayaran
T/T, PayPal, Western Union, L/C
Menyediakan kemampuan
Bulan 10000 pcs
Deskripsi Produk
Flange Mount Hybrid Slip Ring with 30A Power and Fiber Optic Transmission ECN000-02P5-03U2-01EG-01F is CENO flange‑mount multi‑media hybrid slip ring supports endless 360‑degree rotation, combining 30A high‑power circuits, triple USB2.0 channels, Gigabit Ethernet and one fiber‑optic path. Internal partition shielding minimizes crosstalk among power, digital and optical signals. Widened precious‑metal tracks guarantee stable heavy‑current conduction. Every unit undergoes

Tag:

cincin slip digital,

cincin slip tegangan tinggi,

cincin slip bore besar
